In addition to our wide range of Mastercam Core Products, we also offer their complete line of Ad-Ons, from Port and Blade Expert, to Art and File Translator Tools. View our catalogue of Ad-Ons here to learn more about what these products can do for you!
Mastercam Mill-Turn
Mill Turn streamlines programming on complex machines with intelligent job setups that are keyed to the exact machine in your shop.
Mastercam Mill-Turn streamlines programming of high-power multistream machine centers for increased performance and safety. These multitasking CNC machines reduce multiple setups, manual part handling, redundant fixturing, and idle time for improved productivity in manufacturing. Using Mastercam’s proven milling and lathe toolpaths, this software simplifies the programming process for mill-turn machines with job setups keyed to the exact machine in your shop.
- Optimization, synchronization, and visualization in a single platform.
- Automation to easily manage complex operations between multiple machine data streams.
- Efficient milling, turning, and drilling operations with fewer setups at high speed.
- Program simple lathes in addition to complex machines.
Required Core Product
Port Expert
The Port Expert minimizes additional motion at the machine, which creates a more efficient toolpath with a high quality finish.
Mastercam Port Expert facilitates toolpath generation for CNC cylinder head porting. It is a fast and easy-to-use software for creating multiaxis toolpaths within cylinder head ports, complex tubes, or deep pockets. This software creates accurate, efficient porting motion on surface patches or solid body data. It minimizes unnecessary motion at the machine, which results in a highly efficient toolpath with superior finish quality.
- Toolpath motion can be limited to either end of a port or allowed inside both ends of a port, meeting in the middle.
- When cutting from both ends of a port, there is an integrated link move between the cuts, as well a seamless transition where the two cuts meet.
- Port Expert creates finishing motion that runs parallel to, or perpendicular to the flow direction.
Required Core Product
Blade Expert
Complex 5-axis complications is creating toolpaths for impellers, fans, and marine screws alike. The Blade Expert is a custom application that smooths out the toolpath and results in a top quality cut pattern.
Generating toolpaths for impellers, fans, and marine propellers is a complex 5-axis challenge. Machining these multibladed shapes usually requires special multistep, multiaxis programming, but Mastercam Blade Expert provides a comprehensive solution for various blade configurations. The interface follows the Mastercam standard used by all Multiaxis toolpaths, ensuring a short learning curve and successful deployment. Blade Expert turns your multiblade machining challenges into routine solutions:
- Remove the material from between the blades.
- Finish the blades/splitters.
- Finish the floor.
- Finish the fillets.
Required Core Product
Multiaxis
Improve your productivity with simultaneous 4- and 5-axis machining capability for Mastercam. Mastercam Multiaxis offers a wide range of multiaxis machining strategies—both basic and advanced. Multiaxis toolpaths are also very useful for advanced control on 3-axis machines. With Mastercam, you have complete control over three crucial elements of multiaxis machining: cut pattern, tool axis control, and collision avoidance. Tilt axis limits control the tool angle to ensure the toolpath will not violate machine tool limits.
- Delivers multisurface 5-axis roughing and finishing, including stock model awareness.
- Tilt axis limits control the tool angle to ensure the toolpath will not gouge your part or violate machine tool limits.
- Advanced gouge-checking and a 5-axis safe zone around the part help ensure safe cuts in even the most complex operations.
- Works with Mastercam Mill 3D, Mastercam Router 3D, Mastercam Mill-Turn, and Mastercam for SOLIDWORKS® products to generate 5-axis code to run virtually any CNC machine.
- Support for advanced tool geometries is included as standard.
Mastercam Multiaxis ensures accurate cuts and fast turnaround on even the toughest jobs, with streamlined multiaxis programming for optimum productivity.
Required Core Product
Curve/Drill 5-Axis
The curve 5-axis cuts 3D chain or surface edges, and the drill 5-axis simplifies the creation of 3-to-5 axis drilling output for holes in a part.
5-Axis Curve Machining and Drilling helps you make better use of the capabilities that 5-axis machines provide. Your multiaxis machine is capable of drilling holes from different angles with a single fixture setup, saving time and increasing productivity. The power of multiaxis drill becomes apparent on parts that contain multiple holes with center lines pointing in different directions. Tool axis control is what separates multiaxis toolpaths from normal surface, chain, and point toolpaths. The ability to manipulate the angle of the tool, relative to the cut pattern, puts a greater amount of control in your hands. The cut speed, finish quality, and tool life can all be improved with tool axis control.
Mastercam 5-Axis Curve Machining and Drilling is a practical point of entry into multiaxis machining, creating quality toolpaths while reducing programming time.
Required Core Product
ProDrill
Automatically detect, group, and apply drill strategies to large amounts of holes, and even automatically create tool definitions from existing geometry.
Required Core Product
Productivity+
Renishaw Productivity programs and simulates a Renishaw probe for the machine tool you are using. This is a new product that can be integrated into your CNC programs for better productivity.
Productivity+ gives you the ability to use a Renishaw measuring probe on a machine tool to update fixture offsets, tooling offsets, program orientation, and report on critical dimensions and tolerances. It also assists in lights-out manufacturing and running a machine tool without an operator. Productivity+ provides an easy-to-use platform for incorporating simple measurement functionality and more advanced in-process intelligence into machining programs. It can simplify a wide range of measurement and process control tasks, such as component set-up, verification of critical features, and process development.
- Program and simulate a Renishaw probe for your machine tool.
- Improve process control and reporting of your machine tool’s performance.
- Perform simple measurements and alignments to set up and validate your parts at the machine tool.
Productivity+ is a great solution for any shop that wants more control and information about the manufacturing process.
Required Core Product
Art
Quickly bring your 2D sketches, clip art, photos, and CAD files to life by crafting them on-screen and cutting them with easy, specialized toolpaths.
Required Core Product
File Translators
Specialty data translators for UG/NX, Pro/E, and CATIA ensure you can read and use the files you need. Mastercam includes translators for all other standard CAD formats such as Solidworks, Inventor, Autocad, and more!
Required Core Product
Mastercam Swiss
Swiss combines the power of Mill and Lathe with a post processor to address your Swiss needs.
Required Core Product
